HRS Roll Cage Door Swing Out Kit with Integrated Stops

After years of using generic billet swing-out kits, we decided it was time to build one that solved the problems racers deal with every day.

The HRS Roll Cage Swing-Out Kit features our own proprietary design with a precision-machined fit that dramatically reduces the slop and bar drop commonly found in generic swing-out kits. Even more importantly, it incorporates a positive mechanical stop that acts as a built-in backstop, addressing a key requirement found in NHRA regulations.

The mating components are machined to dead-stop when closed, preventing the swing-out bar from rotating past its intended position. This not only provides a solid, repeatable fit but also adds an extra layer of safety should the quick pin ever be forgotten or fail.

As an added bonus, the swing-out incorporates a 55-degree opening stop, preventing the bar from swinging into your open door and damaging the paint or sheet metal.

Designed to fit 1-5/8" x .083" tubing, this kit is an excellent choice for race cars that require easy entry and exit without compromising strength or function.

Features

• Exclusive HRS design
• Precision-machined fit minimizes play and bar drop
• Positive mechanical stop provides a built-in backstop
• Dead-stop design prevents over-rotation when closed
• Integrated 55° opening stop helps protect your doors
• Fits 1-5/8" x .083" tubing
• Precision machined from 1045 steel
• Includes:
  • Grade 8 mounting bolt
  • Grade 8 lock nut
  • Quick-release pin
• Made in the USA

One kit completes one swing-out.
Order two (2) kits to equip both doors.
